ZEISS Automated Defect Detection

Automated defect detection you can trust

The software ZEISS Automated Defect Detection allows detecting and evaluating even the smallest defects in castings reliably, quickly and automatically. Machine learning makes it possible!

Your advantages:
  • Defect analysis in only 60 seconds
  • Reliable evaluation
  • Comprehensive reporting

Detect defects in castings

During the complex manufacturing process of castings, a wide range of defects can occur. On the inside they can have a great impact on the stability and functionality of the part. Industrial computed tomography makes these hidden flaws visible. The ideal solution is the evaluation software ZEISS Automated Defect Detection. It allows you to analyze and evaluate defects reliably and at an early stage.

Defect analysis in only 60 seconds

In order to avoid unnecessary scrap early on, the 3D data, which is captured with the inline computed tomography systems of the ZEISS VoluMax family, has to be evaluated reliably and quickly when inspecting light metal parts. In only 60 seconds, the evaluation software ZEISS Automated Defect Detection examines 4 billion voxels, i.e. 3D pixels, for defects as large as 10 voxels. Parts with critical defects are, thus, reliably sorted out, while good parts pass through the further processing steps. The result: a lower scrap rate and high quality castings.

Find defects reliably

Machine learning is the key to reliable defect detection: ZEISS Automated Defect Detection creates a so-called "golden part" as a reference from several good parts. This makes it possible to detect defects even in poor image quality with many artifacts. Scattered radiation no longer leads to false negative results – but pores, blowholes, cracks, sand residues and even the smallest porosities stand out immediately. If necessary, you can regenerate the "golden part" in no time at all, for example if the shape of the part changes or you want to evaluate another part. This simplifies changeovers in production and saves time.

Reliable evaluation

If ZEISS Automated Defect Detection detects a defect, the software evaluates it in terms of location, shape, size and type. For example, if pores are close to a surface that is being processed in the following production steps, they may pose a greater risk than at another location. This also allows predictions to be made as to whether problems may occur during later processing steps. The part is automatically sorted out at an early stage and you save costs for processing. The evaluation software also allows you to define the criteria under which a defect still meets quality standards and when it is classified as critical. So, with ZEISS Automated Defect Detection, you get a solution that is precisely tailored to your requirements.

Blank modern computer monitor isolated on white background with clipping path
Blank modern computer monitor isolated on white background with clipping path

Comprehensive reporting

If the software detects a critical defect, it creates a report with ZEISS PiWeb. This allows you to view and evaluate the defects again in a 3D view. This is because some defects, such as sand residues, can be easily removed, thus further unnecessary scrap is reduced and costs are saved.

Do you need more information about ZEISS Solutions for Light Metal Applications?

Fill out the form below to download our brochure.
